User’s Manual of GSW-4804SF
-11
„ GSW-4804SF_192.168.0.222 Core-Switch VLAN Configuration
192.168.0.222 VLAN Configuration
Port Link Type PVID Egress Link Partner
Port1 Always Untag 1 Untag=1,2,3,4 Server
Port5 Trunk 1 Tag=1,2,3,4 192.168.0.30
Port6 Trunk 1 Tag=1,2,3,4 192.168.0.20
Port7 Trunk 1 Tag=1,2,3,4 192.168.0.10
„ WGSW-2840_192.168.0.10 Edge-Switch VLAN Configuration
192.168.0.10 VLAN Configuration
Port Link Type PVID Egress Link Partner
Port1 Always Untag 2 Untag=1,2 PC
Port2 Always Untag 2 Untag=1,2 PC
Port3 Always Untag 2 Untag=1,2 PC
Port18 Always Untag 1 Untag=1,2,3,4 NtworkPrinter
Port28 Trunk 1 Tag=1,2,3,4 Core-GSW-4804SF
„ WGSW-2840_192.168.0.20 Edge-Switch VLAN Configuration
192.168.0.20 VLAN Configuration
Port Link Type PVID Egress Link Partner
Port1 Always Untag 3 Untag=1,3 PC
Port2 Always Untag 3 Untag=1,3 PC
Port3 Always Untag 1 Untag=1,2,3,4 NtworkPrinter
Port28 Trunk 1 Tag=1,2,3,4 Core-GSW-4804SF
„ WGSW-2840_192.168.0.30 Edge-Switch VLAN Configuration
192.168.0.30 VLAN Configuration
Port Link Type PVID Egress Link Partner
Port1 Always Untag 4 Untag=1,4 PC
Port2 Always Untag 4 Untag=1,4 PC
Port3 Always Untag 4 Untag=1,4 PC
Port28 Trunk 1 Tag=1,2,3,4 Core-GSW-4804SF
