User’s Manual of GSW-4804SF
-43-
4.3.6 Buffer Schedule
This section provides Buffer Schedule for the system and the screen in Figure 4-37 appears. Table 4-9 describes the Buffer
Schedule object of the Switch.
Figure 4-37 Buffer Schedule Web Screen
Table 4-9 Descriptions of the Buffer Schedule Web Screen Objects
#
Notice: When the configuration changed, please save current configuration and reboot the Switch for take affect.
O Object Description
Buffer Dispatch Schedule
Default Set the system run at default buffer allocation mode, this mode will not drop the packets when the
Switch buffer zone is full.
Recommendatory1 Set the system run at Recommendatory1 allocation mode, this mode will drop the packets when the
Switch buffer zone is full.
Apply button Press this button to take affect.
