User’s Manual of GSW-4804SF
-95-
Table 4-45 Descriptions of the Facility Protection Web Screen Objects
O Object Description
Host Bandwidth Restriction
Enable Host←→Router Bandwidth Restriction Allow Disable or Enable the Router Bandwidth Restriction, default is Disable.
Apply button Press this button to take affect.
DHCP Server Protection
Enable DHCP Server Protection Function Allow Disable or enable the DHCP Server Protection Function, default is
Disable .
Apply button Press this button to take affect.
Route Port Speed Restriction
IP Address Allow input one router IP address for speed restriction.
Speed Restriction(100-1000000) Allow assign value for speed restriction and the available range is 100-1000000
kbps.
Apply button Press this button to take affect.
Show Route Port Speed Restriction
IP Address Display the router IP Address.
Equipment Name Display the equipment name of the router.
Port Display the port that connected to the router.
Speed Restriction(Kbps) Display the value of speed restriction in Kbps.
Delete button Press this button to delete one specific choose item.
