User’s Manual of GSW-4804SF
-19-
3.4 Web Management Access
The PLANET GSW-4804SF provides built-in browser interface. You can manage the Switch remotely by having a remote host
with Web browser, such as Microsoft Internet Explorer, Netscape Navigator or Mozilla Firefox.
The following shows how to startup the Web Management of the Switch, please note the Switch is configured through an
Ethernet connection, make sure the manager PC must be set on the same IP subnet address, for example, the default IP
address of the Switch is 192.168.0.100 (the factory-default IP address), then the manager PC should be set at 192.168.0.x
(where x is a number between 1 and 254, except 100), and the default subnet mask is 255.255.255.0.
Use Internet Explorer 5.0 or above Web browser. Enter the factory-default IP address to access the Web interface. The
factory-default IP Address as following:
http://192.168.0.100
When the following login screen appears, the system will ask you to enter the username and password.
Default User Name: admin
Default Password: admin
The login screen in Figure 3-2 appears.
Figure 3-2 Web Login Screen of GSW-4804SF
After entering the username and password (default user name and password is “admin”) in login screen ( Figure 3-2 appears).
The Web main screen appears as Figure 3-3 .
