User’s Manual of GSW-4804SF
-37-
Table 4-3 Descriptions of the Port Configuration Web Screen Objects
#
Notice: Due to the hardware restriction. The flow control function cannot across between port 1-24 and port 25-48.
O Object Description
Port Configuration
Port List
Allow choose one or multi-ports for configuration.
Management Status Allow choose Disable or Enable for one or multi-ports, the default mode is Enable.
Speed/ Duplex Allow defining various speed duplex modes for each port, the available options are Auto, 10H, 10F,
100H, 100F, 1000F. The default mode is Auto.
Flow Control Allow choose Disable or Enable the Flow Control for one or multi-ports, the default mode is Enable.
Apply button Press this button to take affect.
Port Status
Port Indicate the port 1 to port 48 of the Switch.
Management Status Display per port Management Status of the Switch.
Link Status Display per port Link Status of the Switch.
Config Indicate the Speed mode that user configured on each port of the Switch.
Speed
Actual Indicate the current Speed mode on each port of the Switch.
Config Indicate the Duplex mode that user configured on each port of the Switch.
Duplex
Actual Indicate the current Duplex mode on each port of the Switch.
Config Indicate the Flow Control mode that user configured on each port of the Switch. Flow
Control Actual Indicate the current Flow Control mode on each port of the Switch.
Refresh button Press this button to refresh the Port Status screen.
