User’s Manual of GSW-4804SF
-84-
Table 4-34 Descriptions of the Port Analysis Web Screen Objects
O Object
Description
Port Selecting
Port
Allow choose one port for detail traffic transmits / receives statistics display.
Apply button
Press this button to take affect.
Show Statistic Table
Statistics Item
Tx bytes:
Displays the value of packets transmits from choose port and the unit is bytes.
Tx packets:
Displays the value of packets transmits from choose port and the unit is packets.
Rx bytes:
Displays the value of packets receives from choose port and the unit is bytes.
Rx packets:
Displays the value of packets receives from choose port and the unit is packets.
Received flow control pakets:
Display the value of flow packets receives from chooses port.
Send flow control pakets:
Display the value of flow packets transmits packets from chooses port.
Rx Unicast packets:
Display the value of Unicast packets receives from chooses port.
Rx Multicast packets:
Display the value of Multicast packets receives from chooses port.
Rx Broadcast packets:
Display the value of Broadcast packets receives from chooses port.
Tx/Rx packets of 64 bytes:
Display the value of 64bytes packets transmit / receive from choosed port.
Tx/Rx packets of 65~127 bytes:
Display the value of 64 to 127bytes packets transmit / receive from choosed port.
Tx/Rx packets of 128~255 bytes:
Display the value of 128 to 255bytes packets transmit / receive from choosed port.
Tx/Rx packets of 256~511 bytes:
Display the value of 256 to 511bytes packets transmit / receive from choosed port.
Tx/Rx packets of 512~1023 bytes:
Display the value of 512 to 1023bytes packets transmit / receive from choosed port.
Tx/Rx packets of more than 1024 bytes: Display the value of 1024bytes packets or above transmit / receive from choosed port.
Total
Display the total value from statistics items.
Average
Display the average value from statistics items.
Max
Display the maximum value from statistics items.
Refresh
Press this button to refresh the statistics table.
