User’s Manual of GSW-4804SF
-21-
4. WEB CONFIGURATION
The PLANET GSW-4804SF can be configured through an Ethernet connection, make sure the manager PC must be set on
same the IP subnet address with the Switch. For example, if you have changed the default IP address (192.168.0.100) of the
Switch to 192.168.1.1 with subnet mask 255.255.255.0 via Web interface, then the manager PC should be set at 192.168.1.x
(where x is a number between 1 and 253) with subnet mask 255.255.255.0. Or you can use the factory default IP address
192.168.0.100
to do the relative configuration on manager PC. The sceen in
Figure 4-1
appears.
Figure 4-1
Web Management via Ethernet
Logging on the Switch
1.
Use Internet Explorer 5.0 or above Web browser. Enter the factory-default IP address to access the Web interface. The
factory-default IP Address as following:
http://192.168.0.100
2.
When the following login screen appears, the system will ask you to enter the username and password.
Default User name: admin
Default Password: admin
The login screen in
Figure 4-2
appears.
