User’s Manual of GSW-4804SF
-7-
1.3 Product Feature
¾ Physical Port
48-Port 10/100/1000Base-T RJ-45
4 SFP slots, shared with Port-45, Port-46, Port-47 and Port-48
RS232 Console interface for reset system to factory default mode
¾ Layer 2 Features
Complies with the IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z Gigabit Ethernet standard
Per port supports Auto-negotiation, 10Base-T / 100Base-TX Half-Duplex / Full-Duplex modes and 1000Base-T
Full-Duplex mode.
Auto-MDI/MDI-X detection on each RJ-45 port
Prevents packet loss with back pressure (Half-Duplex) and IEEE 802.3x PAUSE frame flow control (Full-Duplex)
High performance Store and Forward architecture, broadcast storm control, runt/CRC filtering eliminates erroneous
packets to optimize the network bandwidth
16K MAC address table, automatic source address learning and ageing
9K Jumbo frame size
49 Port based VLAN groups / 512 IEEE 802.1Q Tagged based VLAN groups support
Support up to 12 Link Aggregation groups, each group for up to maximum 8 port with 16Gbps bandwidth( Full Duplex
Mode)
Port Mirroring to monitor the incoming or outgoing traffic on a particular port
Per port disable / enable, speed duplex mode / Flow control setting
Per port Link Status test
¾ Quality of Service
Support for strict priority and Weighted Round Robin (WRR) CoS policies
Support QoS and bandwidth control on each port
¾ Multicast
Support IGMP Snooping V1/V2, up to 256 multicast Groups
Support IGMP Route Port
¾ Security
MAC-Based Access Control List
IP-Based Access Control List (ACL)
TCP/UDP/ICMP Access Control List (ACL)
Security Defense / ARP Defense
Port Security for MAC address binding / filtering / learning / aging time setting
Management
Web-based management
Management VLAN for high security access limit
Web firmware upgradeable
Web configuration backup / recovery
EMI standards comply with FCC, CE class A
