DIVA system 64
© 2012 ATEÏS
4.1.1.9.2 EVAC Zone List
In the event of an evacuation state in the DIVA system, the Evac zone Info List will be automatically
display as a priority display. With the up and down arrow keys, you can go through the different
evacuation process occurring in the system.
The youngest evacuation state/occurrence is displayed first. The evacuation status is displayed as
follow:
1st line: EVAC ZONE LIST
2nd line: XXXXXXXX
Note: the XXXXXX depends on the name of the evacuation event used.
4.1.1.9.3 Fault List
In the event of a fault state in the DIVA system, the Fail Info List will be automatically displayed. With
the up and down arrow keys, you can go through the different live fault occurrences in the system.
The youngest fault state/occurrence is displayed first. The fault state is displayed as follow:
1st line: FAULT LIST
2nd line: The fault message shows here
4.1.1.9.4 Events List
In the event of any non-evacuation audio routing in the DIVA system, the Normal Info List will be
automatically displayed. With the up and down arrow keys, you can go through the different evacuation
process occurring in the system.
The youngest evacuation state/occurrence is displayed first. The normal paging/audio routing status is
displayed as follow:
1st line: EVENTS LIST
2nd line: The event status shows here
4.1.1.9.5 Scheduler List
In the event of all scheduler lists in the DIVA system, the Task List will be automatically display as a
priority display. With the up and down arrow keys, you can go through the different task name in the
system.
The youngest task name is displayed first. The ON/OFF is displayed as follow:
1st line: 001/001 SCHEDULER LIST
2nd line: Task1 OFF
4.1.1.9.6 Setting Menu
The function menu allows to set and read system configuration parameters. All the following menus and
setting are available from front panel:
