Chapter 5: Monitor, Diagnostic, Maintenance
Monitor, Diagnostic, Maintenance

NGSME16T2H User Manual | 286

Port State

The current state of the port. Refer to NAS Port State for a description of the

individual states.

Last Source

The source MAC address carried in the most recently received EAPOL frame for

EAPOL-based authentication, and the most recently received frame from a new

client for MAC-based authentication.

Last ID

The user name (supplicant identity) carried in the most recently received Response

Identity EAPOL frame for EAPOL-based authentication, and the source MAC

address from the most recently received frame from a new client for MAC-based

authentication.

QoS Class

QoS Class assigned to the port by the RADIUS server if enabled.

Port VLAN ID

The VLAN ID that NAS has put the port in. The field is blank, if the Port VLAN ID is

not overridden by NAS.

If the VLAN ID is assigned by the RADIUS server, "(RADIUS-assigned)" is

appended to the VLAN ID. Read more about RADIUS-assigned VLANs here.

If the port is moved to the Guest VLAN, "(Guest)" is appended to the VLAN ID. Read

more about Guest VLANs here.

Buttons

Refresh: Click to refresh the page immediately.

Auto-refresh: Click this box to enable an automatic refresh of the page at regular

intervals.

Port State

Admin State

The port's current administrative state. Refer to NAS Admin State for a description of

possible values.

Port State

The current state of the port. Refer to NAS Port state for a description of the

individual states.

QoS Class

The QoS class assigned by the RADIUS server. The field is blank if no QoS class is

assigned.
