Security / Switch / Access Management Configuration
The Access Management mode allows user to limit the switch access with specific
range of IP address and disable some remote management service, such HTTP,
HTTPS, SNMP, Telnet and SSH. This feature is important while user installed the
switch on network. After enabled the Access Management, only the pre-configured
IP address or a range of IP address can access the switch management interface,
and only the available service can be accessed.
Configure access management table on this page. The maximum entry number is
16. If the application's type match any one of the access management entries, it will
allow access to the switch.
Example of the below figure, only the IP Addresses range from 192.168.2.101 to
192.168.2.200 can access the switch's management interface. The available
services are HTTP, HTTPS, SNMP, Telnet and SSH. If there is one IP address,
192.168.2.201 try to open the web management interface, it is not allowed.
Mode
Indicates the access management mode operation. Possible modes are:
Enable: Enable access management mode operation.
Disabled: Disable access management mode operation.
Delete
Check to delete the entry. It will be deleted during the next save.
Start IP address
Indicates the start IP address for the access management entry.
End IP address
Indicates the end IP address for the access management entry.
With the Start and End IP address, you can assign a range of IP addresses.
HTTP/HTTPS
Indicates that the host can access the switch from HTTP/HTTPS interface if the host
IP address matches the IP address range provided in the entry.
