Chapter 5: Monitor, Diagnostic, Maintenance
Monitor, Diagnostic, Maintenance
NGSME16T2H User Manual | 288
Type
not recognized.
Rx
Invalid
Length
dot1xAuthEapLengthErrorFramesRx
The number of EAPOL frames that have been
received by the switch in which the Packet Body
Length field is invalid.
Tx
Total
dot1xAuthEapolFramesTx
The number of EAPOL frames of any type that
have been transmitted by the switch.
Tx
Request ID dot1xAuthEapolReqIdFramesTx
The number of EAPOL Request Identity frames
that have been transmitted by the switch.
Tx
Requests
dot1xAuthEapolReqFramesTx
The number of valid EAPOL Request frames
(other than Request Identity frames) that have
been transmitted by the switch.
Backend Server Counters
These backend (RADIUS) frame counters are available for the following
administrative states:
Port-based 802.1X
Single 802.1X
Multi 802.1X
MAC-based Auth.
Backend Server Counters
Direction
Name
IEEE Name
Description
Rx
Access
Challenges
dot1xAuthBackendAccessChallenges
802.1X-based:
Counts the number of times that the
switch receives the first request
from the backend server following
the first response from the
supplicant. Indicates that the
backend server has communication
with the switch.
MAC-based:
Counts all Access Challenges
received from the backend server
for this port (left-most table) or client
