Supervisor Setup
The TOL file defines hole sizes and uniquely identifies them. The format is:
---------------------------------------------------------------------------
---------------------------------------------------------------------------
---------------------------------------------------------------------------
T1 00030
T2 01234
T3 00123
…
The 3 dashed lines are ignored by the QC5200. The number immediately after the T is an identifier (label)
for a hole size. The number immediately after the T identifier is the hole size, in metric units.
Overlays
Templates can include page and report headers and footers. Headers and footers are created of text and
graphic images, and are saved in the overlays folder to be recalled and added to pages or reports later.
Overlay files have the following extension:
.5io
Parts
Part files contain all aspects of a part including geometric features, part view and program. Part files have
the following extension:
.5pa
Templates
Template files can be created by the user to organize program, feature, report and other information into
columns in the report window. Template files have the following extension:
.5ft
Workspaces
Workspace files contain all aspects of the arrangement of user interface screens. These files can be recalled
by different users to display the user interface in a manner that suits their individual needs. Workspace
files do not include other QC5200 system settings and can be recalled without changing measurement or
display parameters. Workspace files have the following extensions:
.5ws
Filenames
