Power element
6
Wiring
6.6
Power element
6600
Power element
6-
6.6.1
Mains voltage
Mains voltage
6-
][Verdr_Leiterquerschnitte_Verweis
Under “Connection cables”, please note the requirements for the:
`
Cable cross sections
`
Insulation material
][Verdr_Netz_protego_D
Please note the following important points under “Mains voltage”, in the
chapter entitled “Function Description”:
`
The mains voltage requirements (network configurations)
`
The use of isolating transformers
Connector pin assignment
Connector X0
Pin
Designation
Description
1
PE
Earth conductor
2
L3
Mains voltage phase L3
3
L2
Mains voltage phase L2
4
L1
Mains voltage phase L1
Connection
Mains voltage for power element
Three-phase
X0
1 PE
2 L3
3 L2
4 L1
1
L3
2
3
4
PMCprotego
X0
L1
L2
PE
L3
L1
L2
PE
FN3
FN1
FN2
