7-15
7.5
Messages/errors
7
Commissioning
* from firmware V5.xx: These error messages must be reset with
DRVCNFG3 = 16. All other error messages can be cleared without a
hardware reset using the CLRFAULT parameter.
F17*
A/D Converter
Error in the analogue/digital conversion, often
caused by very strong electromagnetic inter-
ference
F18*
Brake chopper
Brake circuit defective or incorrect setting
F19
Intermediate circuit
Voltage drop in the intermediate circuit
F20*
Expansion card error
Slot error, depends on the expansion card
that's used, see ASCII command reference
F21*
Handling error
Handling error on the expansion card
F22
Reserved
Reserved
F23*
CAN Bus off
Major CAN Bus communication error
F24
Warning
Warning indicator assessed as an error
F25*
Commutation error
Commutation error
F26
Limit switch
Reference run error (hardware limit switch
reached)
F27*
STO
Operational error with STO, STO-ENABLE and
ENABLE inputs set simultaneously
F28
Fieldbus error
See also: ASCII command reference
F29
Fieldbus error
Communication disrupted, see ASCII com-
mand reference
F30
Emergency timeout
Timeout E-STOP
F31
Safety card error
Safety card's reaction monitoring is register-
ing an error.
F32*
System error
System software responds incorrectly
No.
Error message
Description
