4-7
4.2
Power element
4
Function Description
Fig. 4-4:
Timing diagram for motor holding brake
`
The speed setpoint is brought from 100 ms to 0 within the internal de-
lay time (internal ENABLE). The emergency braking ramp DECDIS is
selectable.
`
The brake output BR+ switches at a speed of 5 rpm or after 5 s at the
latest (EMRGTO).
`
The rise times (t
brH
) and fall times (t
brL
) of the motor holding brake de-
pend on the motor type (see motor documentation).
Safe actuation of the motor holding brake
Safe actuation of the holding brake also requires:
`
The N/O contact from a safety relay within the braking circuit
`
A suppression device (e.g. varistor or flywheel diode).
][Funktion_Motorhaltebremse_protego_D_01_24_Schaltung
Analog-in
X3B/9-10
ENABLE
X3A/1
n-Setpoint value
internal
Brake BR+
X9/2-1
Motor speed
ENABLE
internal
Braking power
STO
Emergency braking ramp
TBRAKE0 def. 20 ms
Ramp+
TBRAKE def. 100 ms
EMRGTO
max. 5 s
VEL0
DECDIS
tbrH
tbrL
5
t
t
t
t
t
t
t
t
U
U
U
U
U
U
n
F
