5-1
5.1
General requirements
5
Installation
5
5000
Installation
Installation
5-
5.1
General requirements
5100
General requirements
5-
][Montage_Einbauort
Mounting location
`
The servo amplifier should be installed in an enclosure, e.g. control
cabinet, that conforms to the protection class required for the envi-
ronment.
`
The mounting location must be free from conductive and aggressive
materials.
`
Make sure you keep the necessary space clear above and below the
servo amplifier (see section entitled “Installing the servo amplifier”)
][Montage_Umgebung
Environmental conditions
`
When installing the system in an enclosure such as a control cabinet,
the environmental data for the servo amplifier must be taken into ac-
count. Details can be found in the chapter entitled “Technical Details”.
`
Protect the servo amplifier from undue stress. In particular, do not al-
low any components to become bent and/or insulation distances to
be modified during transportation and handling.
`
Make sure there is an adequate flow of cool, filtered air from the bot-
tom of the control cabinet or use a heat exchanger. Please note the
ambient temperature of 0 - 40 °C with nominal data, 40 - 55 °C with
power derating 2.5 %/K.
`
In extreme ambient conditions, additional measures may be required
in order to keep within the prescribed value range.
][Montage_Erdung
Earthing, EMC
`
Make sure that the servo amplifier and motor are earthed correctly.
Do not use varnished (non-conductive) mounting plates.
`
Components that generate magnetic fields should not be installed di-
rectly next to the servo amplifier. If necessary, shield the magnetic
fields.
][Montage_Entladung
`
Damage due to electrostatic discharge!
Electrostatic discharge can damage components. Ensure discharge
before touching the servo amplifier, e.g. by touching an earthed, con-
ductive surface or by wearing an earthed armband.
][Montage_Netzteil
Power supply
`
The servo amplifier and power supply should be installed close to
each other on the conductive, earthed mounting plate inside the con-
trol cabinet.
][Montage_Schaltschrankbeleuchtung
Control cabinet lighting
`
Use low interference panel lighting for inside the control cabinet.
