4-57
4.5 Switch on/switch off behaviour
4 Function Description
Even if there is no intervention from an external control system (in this
example, the ENABLE signal remains active), the motor is immediately
braked using the emergency braking ramp if an input phase fault is de-
tected and the factory default setting is unchanged (ACTFAULT = 1).
][Funktion_Ein_Aus_Hinweis
NOTICE
Please note the following when using a safety card PMCprotego
S: Before setting the servo amplifier enable, the "Ready" output
on the safety card (X30/16) must be polled!
