4.2
Power element
4
Function Description
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
4-4
Requirements for isolating transformers
`
An earthed star point must be available on the secondary side. The
star point on the secondary side must be earthed and must be con-
nected to the servo amplifier's protective earth conductor. This will
prevent overvoltages between the external conductors and the servo
amplifier housing.
`
The isolating transformers must have the relevant input and output
voltages.
The following illustration shows the connection types.
