6.7 Control element
6 Wiring
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
6-28
Connection
Input circuit Resolver
Thermal switch in the motor is con-
nected via the resolver cable at X2
Twisted pair, shielded
Shield connection in the connector
7
S2 (Sin1)
S4 (Sin2)
3
4
8
S1 (Cos1)
R2 (Ref2)
PMCprotego X2
Shield
5
9
2
6
1
R1 (Ref1)
J
J
J
M
Resolver
S3 (Cos2)
S2
S4
S1
R2
R1
S3
PMCtendo AC
2
3
1
6
7
11
10
9
