103
Input/output signal settings
Setting the HDMI input signals
Set the HDMI input signals when the HDMI input unit
(optional) or full-HD HDMI input unit (optional) has been
connected.
Signals with the following resolutions can be input.
HDMI input signals
Standard
(Digital)
HDMI Input Unit
(Digital)
AV-UHS5M3
XGA
(1024×768)/60 Hz
 
WXGA
(1280×768)/60 Hz
 
SXGA
(1280×1024)/60 Hz
 
WSXGA+
(1680×1050)/60 Hz
 
UXGA
(1600×1200)/60 Hz
 
WUXGA
(1920×1200)/60 Hz
 
WQHD
(2560×1440)/60 Hz
 
720/59.94p
(1920×1080)/59.94 Hz
 
720/50p
(1920×1080)/50 Hz
 
1080/59.94i
(1920×1080)/59.94 Hz
 
1080/50i
(1920×1080)/50 Hz
 
1080/23.98p
(1920×1080)/23.98 Hz
 
1080/25p
(1920×1080)/25 Hz
 
1080/29.97p
(1920×1080)/29.97 Hz
 
1080/59.94p
(1920×1080)/59.94 Hz
 
1080/50p
(1920×1080)/50 Hz
 
2160/59.94p
(3840×2160)/59.94 Hz
 
2160/50p
(3840×2160)/50 Hz
 
 : Can be set.
—: Cannot be set.
p p If signals with any other resolutions or frequencies are
input, the signals cannot be imported correctly.
The images which are output at a time like this may be
black or disturbed.
p p These units are incompatible with the HDCP (High-
bandwidth Digital Content Protection).
1 On the Input sub menu, use [F2] to select the input to
be set using the Select item.
 Refer to “Input signal settings”.
2 Use [F1] to display the HDMI Input sub menu.
3 Use [F2] to select the scaling method.
Fit-V The aspect ratio of the input images is
maintained, and the size of the images is
increased or reduced in accordance with the
vertical resolution.
Fit-H The aspect ratio of the input images is
maintained, and the size of the images is
increased or reduced in accordance with the
horizontal resolution.
Full The size of the input images is increased
or reduced in accordance with the system
resolution.
(The aspect ratio of the input images is not
kept the same. The rate at which the image
size is increased or reduced in the vertical
direction and in the horizontal direction
differs.)
