Menu
Sub menu Parameter 1 Parameter 2 Parameter 3 Parameter 4
Use [F1] to select. Use [F2] to select. Use [F3] to select. Use [F4] to select. Use [F5] to select.
Multi View Display
When MV1
MV1 Split Parameter Split
Setting range 4Split, 5-aSplit,
5-bSplit,
6-aSplit,
6-bSplit, 9Split,
10-aSplit,
10-bSplit,
12Split, 16Split
Default value 10-aSplit
MV1 Pattern
1/4 Parameter Pos1 Signal Pos2 Signal Pos3 Signal Pos4 Signal
Setting range IN1, IN2, SDI IN3, SDI IN4, SDI IN5, SDI IN6, SDI IN7, SDI IN8, IN-
A1, IN-A2, IN-A3, IN-A4, IN-B1, IN-B2, IN-B3, IN-B4, CBGD 1, CBGD
2, Still 1V, Still 1K, Still 2V, Still 2K, Clip 1V, Clip 1K, Clip 2V, Clip
2K, PGM, PVW, CLN, ME PGM, Key Out, MV1, MV2, AUX1, AUX2,
AUX3, AUX4, Clock
Default value PGM PVW IN1 IN2
MV1 Pattern
2/4 Parameter Pos5 Signal Pos6 Signal Pos7 Signal Pos8 Signal
Setting range The setting range is the same as for the MV1 Pattern 1/4 sub menu.
Default value SDI IN3 SDI IN4 SDI IN5 SDI IN6
MV1 Pattern
3/4 Parameter Pos9 Signal Pos10 Signal Pos11 Signal Pos12 Signal
Setting range The setting range is the same as for the MV1 Pattern 1/4 sub menu.
Default value SDI IN7 SDI IN8 Still 1V Still 2V
MV1 Pattern
4/4 Parameter Pos13 Signal Pos14 Signal Pos15 Signal Pos16 Signal
Setting range The setting range is the same as for the MV1 Pattern 1/4 sub menu.
Default value Clip 1V Clip 2V AUX1 AUX2
MV1 Frame Parameter Frame Character Label
Setting range LUM0%, LUM25%, LUM50%,
LUM75%, LUM100%, Off On, Off
Default value LUM75% On
MV1 Tally
Group1 Parameter Box Label Left Label Right
Setting range On, Off On, Off On, Off
Default value Off Off Off
MV1 Tally
Group2 Parameter Box Label Left Label Right
Setting range On, Off On, Off On, Off
Default value Off Off Off
Display Parameter Level Meter Input Status Marker Marker Size
Setting range On, Off On, Off 4:3, 16:9, Off 80 to 100%
Default value Off On Off 95%
Setting menu table
