Table 9-12: DPTX0_MSA_VSP Bits
Bit
Bit Name
Function
31:1
Unused
0
VSP
Main stream attribute vertical
sync polarity
• 0 = Positive
• 1 = Negative
DPTX0_MSA_VSW
Address: 0×0029
Direction: RO
Reset: 0×00000000
Table 9-13: DPTX0_MSA_VSW Bits
Bit
Bit Name
Function
31:15
Unused
14:0
VSW
Main stream attribute vertical
sync width
DPTX0_MSA_HWIDTH
Address: 0×002a
Direction: RO
Reset: 0×00000000
Table 9-14: DPTX0_MSA_HWIDTH Bits
Bit
Bit Name
Function
31:16
Unused
15:0
HWIDTH
Main stream attribute HWIDTH
DPTX0_MSA_VHEIGHT
Address: 0×002b
Direction: RO
Reset: 0×00000000
UG-01131
2015.05.04
DPTX0_MSA_VSW
9-7
DisplayPort Source Register Map and DPCD Locations
Altera Corporation
