DPTX_MST_VCPTAB3
VC Payload ID Table
Address: 0×00a5
Direction: RW
Reset: 0×00000000
Table 9-33: DPTX_MST_VCPTAB3 Bits
Bit Bit Name Function
31:28
VCPSLOT31 VC payload ID or slot 31
27:24
VCPSLOT30 VC payload ID or slot 30
23:20
VCPSLOT29 VC payload ID or slot 29
19:16
VCPSLOT28 VC payload ID or slot 28
15:12
VCPSLOT27 VC payload ID or slot 27
11:8
VCPSLOT26 VC payload ID or slot 26
7:4
VCPSLOT25 VC payload ID or slot 25
3:0
VCPSLOT24 VC payload ID or slot 24
DPTX_MST_VCPTAB4
VC Payload ID Table
Address: 0×00a6
Direction: RW
Reset: 0×00000000
Table 9-34: DPTX_MST_VCPTAB4 Bits
Bit Bit Name Function
31:28
VCPSLOT39 VC payload ID or slot 39
27:24
VCPSLOT38 VC payload ID or slot 38
23:20
VCPSLOT37 VC payload ID or slot 37
19:16
VCPSLOT36 VC payload ID or slot 36
15:12
VCPSLOT35 VC payload ID or slot 35
