11-5
Appendix > Optional Equipment
(9) PF-780 + PF-740 "Large Capacity Side Feeder (500, 1,500-sheet x 2)"
PF-780 "Multimedia Side Tray (500-sheets)"
Same type of cassette as Cassette 1 on the machine, and is attached to the Paper Feeder (500-sheet x 2) or Large
Capacity Feeder (1,500-sheet x 2).
PF-740 "Large Capacity Feeder (1,500-sheet x 2)"
In addition to the printer's cassettes, you can also install an optional large capacity feeder (1,500-sheet x 2) capable of
holding up to 3,000 sheets of A4, B5 or Letter paper. Refer to
Cassette 3, Cassette 4, Cassette 6 (PF-740), and
Cassette 7 (PF-740) on page 3-21 for loading paper.
(10) Printed Document Guard Kit(B) "Printed Document Guard Kit"
This prevents the unauthorized copying and/or transmission of documents that contain important confidential or
personal information. When a document is printed from a computer, this feature imprints a special pattern on the
document. When anyone attempts to copy or send that document on this machine, the machine detects the pattern and
protects the information by printing the document in blank and prohibiting transmission.
(11) Keyboard Holder(B) "Keyboard Holder"
A USB keyboard connected to the machine can be placed here.
(12) Card Authentication Kit(B) "Card Authentication Kit"
User login administration can be performed using ID cards. To do so, it is necessary to register ID card information on
the previously registered local user list. For more information about how to register this information, refer to the Card
Authentication Kit(B) Operation Guide.
(13) MM-16-128 "FAX Expansion Memory"
Image storage memory (128 MB) that allows the machine to receive more pages of incoming faxed originals. Expansion
memory should only be installed or removed by the service representative.
(14) Fax System(W) "FAX Kit"
By installing the FAX kit, fax send/receive is enabled. Also, it is possible to use it as a network fax, by using it with a
computer. When two FAX kits are installed, the units can be connected to two different telephone lines which will enable
quicker message transmission to a number of recipients. If one of the lines is dedicated to receiving, the busy line time
can be reduced. For further details, refer to FAX Operation Guide.
(15) IB-50 "Network Interface Kit"
The Network Interface Kit provides a high-speed connection for the Gigabit-per-second interface. Since the kit was
designed to work with TCP/IP, NetWare, NetBEUI, and AppleTalk protocols, it fulfills the network printing demands on
Windows, Macintosh, and UNIX environments. This expansion kit is also compatible with ThinPrint.
(16) IB-51 "Wireless Network Interface Kit"
This is a wireless LAN interface card which supports the wireless LAN specifications IEEE802.11n (Max 300 Mbps) and
11 g/b. With the utilities supplied, settings are possible for a variety of OS and network protocols.
