Tx Dropped (Packets)—Number of packets dropped when they are sent by the AP over the
local mesh link.
{
Tx Errors (Packets)—Number of errors during the transmission of packets through the local
mesh link.
{
Rx Rate (Mbps)—Reception rate of the local mesh link.
{
Rx Packets (Packets)—Number of packets sent by the AP over the local mesh link.
{
Rx Dropped (Packets)—Number of packets dropped when they are received by the AP over
the local mesh link.
{
Remote MAC Address—MAC address of the remote node.
{
Encryption—Type of encryption used on the link.
{
Link to Master—Whether the local mesh link is linked to master or not.
Bridge Status tab
• Bridge List
{
Port—A unique ID assigned to a port. This ID cannot be changed. The last digit in the ID
corresponds to the port number used in the bridge forwarding table.
{
Port Status—State of the LAN port. Options are:
− Listening—Initial state. Port is not forwarding packets, but listens for other bridges.
− Learning—Bridge learns about other bridges on that port. Port is not forwarding packets.
− Forwarding—Port is forwarding packets. Bridge is operational on the port.
− Blocking—Port is not forwarding. A loop was detected in the bridging network.
{
Port Type—Type of port, such as LAN, Ethernet, UDP, and GRE.
• Spanning Tree Protocol List
For definitions of these fields, see the following document, which is available on the Internet:
ANSI/IEEE Std 802.1D, 1998 Edition - Part 3: Media Access Control (MAC) Bridges.
{
Spanning Tree Protocol—Status of the spanning tree protocol.
{
Bridge ID—Bridge unique identifier.
{
Designated Root—MAC address of the root switch.
{
Root Path Cost—Cumulative cost of all links to reach the root switch, based on the values
listed in
Table 16 .
Table 16 Root cost list
Bandwidth STP cost value
4 Mb/s 250
10 Mb/s 100
16 Mb/s 62
45 Mb/s 39
100 Mb/s 19
155 Mb/s 14
622 Mb/s 6
1 Gb/s 4
