NVR 2.3 (V2.3.05.11) User’s Manual
the presets points you wish to add, click
“Add” to add them to the preset point list. Click Return
to return to preset tour page without making any changes.
4.
Delete Preset Point: Click this button to delete preset points of a tour.
5.
Apply: Click this button to save all current settings. If you are editing an existing tour, you
may change the tour name, description and preset setting. If you just clicked
“New tour”,
then pressing apply will add the new tour to the tour list. Be sure to click Apply after
you finished setup, before configuring something else.
6.
Tour ID: Each preset tour has a unique preset tour ID stored in the system. The ID
column is entered automatically by the system
7.
Tour Name: Enter the name of this preset tour
8.
Description: Enter the description of this preset tour
9.
Preset Points Sequence Control Panel: You may rearrange the preset point sequence
here. First click on the row of the preset point you wish to move, then click the buttons to
move to top, move up, move down or move to bottom of list.
10. Preset ID list: All the preset points included in this tour are listed here. Click on the
appropriate row to edit that preset point. You may setup how long will the PTZ camera
stay at each point by selecting from the drop down Dwell time list. Default dwell time is 30
seconds. You may change the value here, but do not use dwell time smaller than 15
seconds unless absolutely necessary.
11. Tour ID list: All tours currently configured are listed here. You may select each tour to
edit the details.
