NVR 2.3 (V2.3.05.11) User’s Manual
recording files. NVR will always delete old files when available space is lower than reserve
space. Select the checkbox for Keep Days to add an additional space management
mechanism. When both are active, NVR will start to clear old files when any of the criterion
is reached.
5. Snapshot delete rule: This field defines how long will snapshots be kept on the disk drive.
Set the number of days to keep snapshots here.
6. Cleanup Space (GB): This is only used when recording delete rule is Reserve Space.
Once free space on the drive is lower than reserve space, the system will delete the
earliest recordings. This is the amount of space to clean out each time. Setting cleanup
space too small will result in over frequent deletes.
7. Selected Drive: Here you can see the storage space information for your disk drives.
8. Shift drive up / down: If you have multiple drives in your system, this changes the priority
in which they are used.
9. New / Delete: These two buttons control whether a drive is added to the system. To add
new disk to be used for NVR storage, select a disk below and click
“New”. To remove a
drive from use, select a disk above and click
“delete”. Please note that removing a disk will
remove database logs of all recordings from that disk. The files will still remain in the disk,
but will no longer be searchable and will not be automatically deleted by NVR upon low
disk space.
10. Available Disk Drives: These are the drives detected by NVR, but not yet included for
video storage use.
Note: When deleting storage drive from system, NVR will delete all recorded logs on this disk.
