Chapter 2 Command System RIGOL
DSG3000 Programming Guide 2-89
[:SOURce]:SWEep:STEP:DWELl
Syntax [:SOURce]:SWEep:STEP:DWELl <value>
[:SOURce]:SWEep:STEP:DWELl?
Description Set the dwell time of step sweep.
Query the dwell time of step sweep.
Parameter Name Type Range Default
<value> Real 20ms to 100s 500ms
Explanation  When <value> is set in "Number" form, the default unit is s. Besides, <value>
can also be set in "Number + Unit" form, for example, 3000ms.
 The default unit of the return value is s.
 After setting the dwell time, you can use the up/down direction keys or knob to
modify the dwell time at the current step. At this point, you can query or set the
current step using the [:SOURce]:SWEep:STEP:DWELl:STEP command.
Return Format The query returns the dwell time of step sweep, for example, 3.
Example :SWE:STEP:DWEL 3 /*Set the dwell time of step sweep to 3s*/
:SWE:STEP:DWEL? /*The query returns 3*/
Related
Command
[:SOURce]:SWEep:STEP:DWELl:STEP
[:SOURce]:SWEep:STEP:DWELl:STEP
Syntax [:SOURce]:SWEep:STEP:DWELl:STEP <value>
[:SOURce]:SWEep:STEP:DWELl:STEP?
Description Set the dwell time step.
Query the dwell time step.
Parameter Name Type Range Default
<value> Real 10ms to 10s 10ms
Explanation  When <value> is set in "Number" form, the default unit is s. Besides, <value>
can also be set in "Number + Unit" form, for example, 3000ms.
 The default unit of the return value is s.
 After setting the dwell time step, you can use the up/down direction keys or
knob to modify the dwell time at the current step. At this point, you can query
or set the dwell time using the [:SOURce]:SWEep:STEP:DWELl command.
Return Format The query returns the dweel time step, for example, 3.
Example :SWE:STEP:DWEL:STEP 3 /*Set the dwell time step to 3s*/
:SWE:STEP:DWEL:STEP? /*The query returns 3*/
Related
Command
[:SOURce]:SWEep:STEP:DWELl
