RIGOL Chapter 2 Command System
2-62 DSG3000 Programming Guide
[:SOURce]:PM:FREQuency
Syntax [:SOURce]:PM:FREQuency <value>
[:SOURce]:PM:FREQuency?
Description Set the modulation frequency of ØM.
Query the modulation frequency of ØM.
Parameter Name Type Range Default
<value> Real
100mHz to 1MHz (Sine)
100mHz to 20kHz (Square)
10kHz
Explanation  When <value> is set in "Number" form, the default unit is Hz. Besides,
<value> can also be set in "Number + Unit" form, for example, 20kHz.
 The default unit of the return value is Hz.
 After setting the modulation frequency, you can use the up/down direction
keys or knob to modify the modulation frequency at the current step. At this
point, you can query or set the current step using the
[:SOURce]:PM:FREQuency:STEP[:INCRement] command.
 This command is invalid when the ØM modulation source is set to "Ext".
Return Format The query returns the ØM modulation frequency, for example, 20000.
Example :PM:FREQ 20kHz
:PM:FREQ?
Related
Commands
[:SOURce]:PM:FREQuency:STEP[:INCRement]
[:SOURce]:PM:SOURce
[:SOURce]:PM:FREQuency:STEP[:INCRement]
Syntax [:SOURce]:PM:FREQuency:STEP[:INCRement] <value>
[:SOURce]:PM:FREQuency:STEP[:INCRement]?
Description Set the modulation frequency step of ØM.
Query the modulation frequency step of ØM.
Parameter Name Type Range Default
<value> Real 100mHz to 500kHz 1kHz
Explanation  When <value> is set in "Number" form, the default unit is Hz. Besides,
<value> can also be set in "Number + Unit" form, for example, 5kHz.
 The default unit of the return value is Hz.
 After setting the modulation frequency step, you can use the up/down
direction keys or knob to modify the modulation frequency at the current
step. At this point, you can query or set the modulation frequency using the
[:SOURce]:PM:FREQuency command.
Return Format The query returns the modulation frequency step of ØM, for example, 5000.
Example :PM:FREQ:STEP 5kHz
:PM:FREQ:STEP?
Related
Command
[:SOURce]:PM:FREQuency
