11. OUTLINE DIMENSION DRAWINGS
(4) MR-E-200A
90 (3.54)
78
(3.07)
16
8
(6.
6
1
)
15
6
(6.
1
4
)
70 (2.76)
195 (7.68)
6
(0.24)
Weight: 2.0 [kg] (4.41 [lb])
[Unit: mm]
([Unit: in])
15
6
(6.
1
4
)
40
(1.58)
6 (
0.
24)
PE terminal
Terminal screw: M4
Tightening torque: 1.2 [N m]
