9469200990 Rev C 127
Table 24. Components Group, Names and Descriptions
Name Description Symbol
Logic Gates
AND Input Output
0 0
0
0 1 0
1 0 0
1 1 1
NAND Input Output
0 0
1
0 1 1
1 0 1
1 1 0
OR Input Output
0 0
0
0 1 1
1 0 1
1 1 1
NOR Input Output
0 0
1
0 1 0
1 0 0
1 1 0
XOR Input Output
0 0
0
0 1 1
1 0 1
1 1 0
XNOR Input Output
0 0
1
0 1 0
1 0 0
1 1 1
NOT
(INVERTER) Input Output
0 1
1 0
Pickup and Dropout Timers
Drop Out
Timer Used to set a delay in the logic.
For more information, refer to Programming BESTlogicPlus, Pickup
and Dropout Timers, later in this section.
Pickup Up
Timer Used to set a delay in the logic.
For more information, refer to Programming BESTlogicPlus, Pickup
and Dropout Timers, later in this section.
DGC-2020ES BESTlogic
™Plus
