TP-Link Omada ER8411 VPN Router - Manual (Page 173)

User Guide 164
Configuring VPN OpenVPN Configuration
Service Port Enter a VPN service port to which a VPN device connects. The default port is 1194.
Local Network Select the network on the local side of the VPN tunnel. The VPN policy will be only
applied to the selected local network.
WAN Select the WAN port on which the VPN tunnel is established. Each WAN port
supports only one OpenVPN tunnel when the gateway works as a OpenVPN server.
IP Pool Enter the IP address and subnet mask to decide the range of the VPN IP pool.
The VPN server will assign IP address to the remote host when the tunnel is
established. You can specify any reasonable IP address that will not cause overlap
with the IP address of the LAN on the local peer router.
Note:
• After saving the settings, export the OpenVPN file that ends in .ovpn which is to be used
by the remote client. The exported OpenVPN file contains the certificate and configuration
information. It may take about 2 minutes to export the certificate.
5.2 Configuring the OpenVPN Client
Choose the menu VPN > OpenVPN > OpenVPN Client and click Add to load the following
page. The router will act as an OpenVPN client to establish the VPN tunnel with the remote
Server.
Figure 5-2 Configuring the OpenVPN Client
