Page 159
125
Step Command
Remarks
2.
Enter interface view.
•
Enter Layer 2 Ethernet
interface view:
interface interface-type
interface-number
•
Enter Layer 2 aggregate
interface view:
interface
bridge-aggregation
interface-number
•
The configuration made in Layer 2
Ethernet interface view applies
only to the port.
•
The configuration made in Layer 2
aggregate interface view applies
to the aggregate interface and its
aggregation member ports. If the
system fails to apply the
configuration to an aggregation
member port, it skips the port and
moves to the next member port. If
the system fails to apply the
configuration to the aggregate
interface, it stops applying the
configuration to aggregation
member ports.
3.
Configure the link type of the
port as access.
port link-type access
By default, all ports are access ports.
4.
(Optional.) Assign the access
port to a VLAN.
port access vlan vlan-id
By default, all access ports belong to
VLAN 1.
Assigning a trunk port to a VLAN
A trunk port supports multiple VLANs. You can assign it to a VLAN in interface view.
When you assign a trunk port to a VLAN, follow these restrictions and guidelines:
•
To change the link type of a port from trunk to hybrid or vice versa, set the link type to access first.
•
To enable a trunk port to transmit packets from its PVID, you must assign the trunk port to the PVID
by using the port trunk permit vlan command.
To assign a trunk port to one or multiple VLANs:
Step Command
Remarks
1.
Enter system view.
system-view
N/A
