Menu List
Menu item Value (bold text: default value) Explanation
LCD Monitor
Specifies the video bus to which this unit’s display is assigned.
Program
Final output video.
Sub Program SUB PROGRAM bus video
Preview Preview output video.
AUX AUX bus video
Multi-View Multi-view.
Input-View
The input video from the HDMI IN and SDI IN connectors (shown as 16 separate sections
on the screen)
Still-View Still images loaded into the unit (shown as 16 separate sections on the screen)
AUX Source
HDMI 1 –6, SDI 1–6,
Still 1–16, V.Player, Input 1–8
Selects the video that is sent to the AUX bus.
When “AUX” is selected on the [MODE] button, you can use the VIDEO SWITCHER [1]–[8]
buttons to select the video that is sent to the AUX bus.
Program Layer
Enter Displays the Program Layer menu.
Menu item Value Explanation
PinP & KEY 1–4 Disable, Enable Sets whether each layer is displayed (Enable) or hidden (Disable) in the final
output video. DSK 1, 2 Disable, Enable
Sub Program Layer
Enter Displays the Sub Program Layer menu.
Menu item Value Explanation
PinP & KEY 1–4 Disable, Enable Sets whether each layer is displayed (Enable) or hidden (Disable) in the Sub
Program bus video. DSK 1, 2 Disable, Enable
AUX Layer
Enter Displays the AUX Layer menu.
Menu item Value Explanation
PinP & KEY 1–4 Off , PGM Sync, On Sets whether each layer in the AUX bus video is shown (On), synced with
PGM (PGM Sync) or hidden (Off). DSK 1, 2 Off , PGM Sync, On
