24
Video Operations
Input scan
1 . On the setup screen for the auto-switching function, touch
<Type> to select “Input Scan”.
The setup screen changes accordingly.
2 . Touch the screen to access the settings.
Menu item Explanation
Scan Sequence
Specifies the order in which video
signals are shown.
Normal:
Switches in the order of Input 1
Ó
8.
Reverse:
Switches in the order of Input 8
Ó
1.
Random:
Switches randomly.
Scan Target
Sets the video to which auto switching
is applied.
Video Input:
Final output video and preview video
PinP & Key 1–4:
PinP and key layer (inset screen) video
DSK 1–2:
DSK layer (inset screen) video
Scan Transition Time Specifies the video transition time.
Input 1–8 Time
Specifies the time that the video is
shown. Turn this “Off” to skip.
* For details on the parameters, refer to “20: Auto Switching” (p. 141).
3 . Press the [SETUP] button to close the screen.
Scene memory scan
1 . On the setup screen for the auto-switching function, touch
<Type> to select “Scene Memory Scan”.
The setup screen changes accordingly.
2 . Touch the screen to access the settings.
Menu item Explanation
Scan Sequence
Specifies the order in which scene memories
are switched.
Normal:
Switches in the order of scene memory 1
Ó
32.
Reverse:
Switches in the order of scene memory 32
Ó
1.
Random:
Switches randomly.
Memory 1–32 Time
Specifies the time it takes to switch to the next
scene memory. Turn this “Off” to skip.
* For details on the parameters, refer to “20: Auto Switching” (p. 141).
3 . Press the [SETUP] button to close the screen.
