Appendix
Ã
Others
Recording Media
SDHC/SDXC card
(commercially available)
* SDXC card is required for video recording.
USB flash drive
(commercially available)
Other Connectors
USB HOST
USB A type (for USB flash drive)
USB STREAM
USB Type-C
®
(for remote control from PC and iPad)
Bluetooth connection
for remote control from iPad
CTL/EXP 1, 2
1/4-inch TRS phone type (for remote control from footswitch and expression pedal)
TALLY/GPIO
DB-25 type (Female)(Tally/GPO: 16, GPI: 8)
RS-232
DB-9 type (Male) (for Remote Control)
DIRECT STREAM
RJ45, 1000BASE-TX (for Live Streaming and Remote Control)
REFERENCE IN/THRU
BNC type
* Black Burst (Sync to frames), Bi-Level, Tri-Level
Other Functions
Scene Memory (32 types), Macro Control (100 types), Sequencer Control (1,000 steps), Panel lock function, EDID Emulator,
Auto Switching, Auto Input Detect, Smart Tally, Remote Camera Control (Up to 12 units), External Rec Control
Bluetooth Function
Ver 5.0
Profile Support
A2DP (Audio), GATT (MIDI over Bluetooth Low Energy)
Codec
SBC (Support to the content protection of the SCMS-T method)
Display
Graphic Type, 7”, Wide VGA (800 x 480 dots), backlite LCD (Color/Touch screen)
Power Supply
AC adaptor
Current Draw
3.0 A
Power
Consumption
69 W
Operation
Temperature
+0 to +40 degrees Celsius
+32 to +104 degrees Fahrenheit
Dimensions
437 (W) x 304 (D) x 109 (H) mm
17-1/4 (W) x 12 (D) x 4-5/16 (H) inches
482 (W) x 304 (D) x 109 (H) mm
19 (W) x 10 (D) x 4-1/16 (H) inches
* When rack mount angles are fitted.
Weight
5.3 kg, 11 lbs 11 oz
(excluding AC adaptor)
Accessories
Startup Guide, Leaflet “USING THE UNIT SAFELY”, AC adaptor, Power cord, Rack-mount angle x 2
Rack-mount angle mounting screw x 6
Options
Footswitch: BOSS FS-5U, FS-6, FS-7
Expression Pedal: EV-5, EV-30, BOSS FV-500L, FV-500H
* 0 dBu = 0.775 Vrms
* This product is a Class A digital device under FCC part 15.
* This document explains the specifications of the product at the time that the document was issued. For the latest information, refer to the Roland website.
