Roland VR-120HD Direct Streaming AV Mixer - Manual (Page 107)

107
Menu List
Menu item Value (bold text: default value) Explanation
When Type = Chroma Key
Window Adjusts the inset screen.
Position H -50.0– -40 .0 –50.0% Adjusts the horizontal position of the inset screen.
Position V -50.0– -40 .0 –50.0% Adjusts the vertical position of the inset screen.
Size 0.0– 35 .0 –100.0% Adjusts the size of the inset screen.
Cropping H 0.0– 100 .0% Adjusts the horizontal size of the inset screen.
Cropping V 0.0– 100 .0% Adjusts the vertical size of the inset screen.
View Adjusts the video that is shown in the inset screen.
Position H -50.0– 0 .0 –50.0% Adjusts the horizontal position at which the inset screen is shown.
Position V -50.0– 0 .0 –50.0% Adjusts the vertical position at which the inset screen is shown.
Zoom 100 –400% Adjusts the zoom of the video shown in the inset screen.
Key Adjusts the key.
Key Level 0– 64 –255 Adjusts the degree of extraction (transparency) for the key.
Key Gain 0 –255 Adjusts the degree of edge blur (semi-transmissive region) for the key.
Mix Level 0– 255 Adjusts the key’s overall density (output level).
Chroma Make detailed settings for chroma key.
Color Green, Blue
Specifies green or blue as the key color (the color to be removed). If you want
a color other than green or blue to turn transparent, use “Sampling Marker
Mode” to specify the key color.
Hue Width -30– 0 –30 Adjusts the hue width for the key color.
Hue Fine 0– 240 –360 Adjusts the center position of the hue for the key color.
Saturation Width -128– 0 –127 Adjusts the saturation width for the key color.
Saturation Fine 0 –255 Adjusts the center position of saturation for the key color.
