Roland VR-120HD Direct Streaming AV Mixer - Manual (Page 133)

133
Menu List
Menu item Value (bold text: default value) Explanation
AUX 2 Bus Adjusts the audio of the AUX 2 bus.
Jump To Setup Enter Jumps to the setup screen.
Level -INF– 0 .0 –10.0dB
Adjusts the output volume.
This can also be adjusted by the [AUX 2] knob.
Mute OFF , ON Turns the mute function on/off. When this is “ON”, the input audio is temporarily silenced.
Solo OFF , ON
Turns the solo function on/off. Only the audio for which this is “ON” is heard in the
headphones.
* The solo function applies to the headphone output. It does not affect output other than
the headphones.
Delay
0 .0 –500msec
(0 –25.0/29.9/30.0frame)
Adjusts the delay time of the audio.
Effect Outputs audio with a delay.
Reverb Return Level -INF– 0 .0 –10.0dB Adjusts how much reverb is sent back to the AUX 2 Bus.
AUX 1 Bus Send Level
Audio In 1–6
-INF –10.0dB Adjusts the amount of audio sent to the AUX bus for each audio input.
Audio In 7/8–9/10
USB In
Bluetooth In
Audio Player
HDMI In 1–6
SDI In 1–6
Video Player
AUX 1 Bus Send Point
Audio In 1–6
Dry,
Pre Fader,
Post Fader
Dry:
Sends the source audio with no effects applied.
Pre Fader:
Sends the effect-applied audio.
The send volume is constant, regardless of the volume (Input Level).
Post Fader:
Sends the effect-applied audio.
The send volume can be changed by adjusting the volume (Input Level).
Audio In 7/8–9/10
USB In
Bluetooth In
Audio Player
HDMI In 1–6
SDI In 1–6
Video Player
Equalizer OFF , ON
Turns the equalizer on/off.
Effect
This is a 4-band parametric equalizer. It lets you shape the character of the sound by boosting
or cutting four frequency regions.
Hi Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the high band.
Hi Freq 1.00– 10 .0 –20.0kHz Adjusts the center frequency when changing the tone quality in the high band.
Hi-Mid Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the high-midrange band.
Hi-Mid Freq 20.0Hz– 2 .00kHz –20.0kHz Adjusts the center frequency when changing the tone quality in the high-midrange band.
Hi-Mid Q 0.5– 1 .0 –16.0
Adjusts the width of the frequency band when boosting or attenuating high-midrange
band.
Lo-Mid Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the low-midrange band.
Lo-Mid Freq 20.0Hz– 500Hz –20.0kHz Adjusts the center frequency when changing the tone quality in the low-midrange band.
Lo-Mid Q 0.5– 1 .0 –16.0 Adjusts the width of the frequency band when boosting or attenuating low-midrange band.
Lo Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the low band.
Lo Freq 20.0Hz– 100Hz –2.00kHz Adjusts the center frequency when changing the tone quality in the low band.
Compressor/Limiter OFF , ON Turns the compressor or limiter on/off.
Type
Selects the compressor or limiter.
Compressor Effect
Audio that exceeds the specified threshold level is compressed. This reduces the difference
between the maximum volume and minimum volume, making the audio more comfortable
for listening
Limiter
Effect Compresses the audio so that the mixed audio does not exceed the specified threshold level.
* Distortion will occur if audio that exceeds the allowable range of the limiter is input.
Compressor
Threshold -50– -8 –0dB
Specifies the level used as the threshold at which the compressor is applied. Compression is
applied to audio that exceeds the threshold.
Ratio
1.00: 1, 1.12: 1, 1.25: 1, 1.40: 1,
1.60: 1, 1.80: 1, 2.00: 1,
2 .50: 1 ,
3.20: 1, 4.00: 1, 5.60: 1, 8.00: 1,
16.0: 1, INF: 1
Specifies the degree of compression applied to the audio. The state in which no compression
is applied is defined as “1”.
Attack 0.0– 30 –100ms Specifies the time until compression starts when audio exceeding the threshold is input.
Release 30– 250 –5000ms Adjusts the length of time until compression ends after audio falls below the threshold.
Makeup Gain -40– 0 –40dB Adjusts the final output volume level after applying the compressor.
Limiter
