Roland VR-120HD Direct Streaming AV Mixer - Manual (Page 156)

156
Appendix
Video Output Formats
HDMI OUT 1–3
SDI OUT 1–3
Output Format
Frame Rate
59.94 Hz 60 Hz 50 Hz
720p 720/59.94p 720/60p 720/50p
1080i 1080/59.94i 1080/60i 1080/50i
1080p 1080/59.94p 1080/60p 1080/50p
Output Format
Frame Rate
29.97 Hz 30 Hz 25 Hz 23.98 Hz 24 Hz
1080p 1080/29.97p 1080/30p 1080/25p 1080/23.98p 1080/24p
USB STREAM
Frame Rate (USB OUT)
59.94 Hz 60 Hz 29.97 Hz 30 Hz
1080/59.94p 1080/60p 1080/29.97p 1080/30p
720/59.94p 720/60p 720/29.97p 720/30p
640×480/59.94p 640×480/60p 640×480/29.97p 640×480/30p
Frame Rate (USB OUT)
50 Hz 25 Hz 23.98 Hz 24 Hz
1080/50p 1080/25p 1080/23.98p 1080/24p
720/50p 720/25p 720/23.98p 720/24p
640×480/50p 640×480/25p 640×480/23.98p 640×480/24p
* Uncompressed format (YUY2) and Compressed format (Motion JPEG) supported.
Stream and Record
formats
Output Format
Frame Rate (Stream/Record)
59.94 Hz 60 Hz 29.97 Hz 30 Hz
720p 720/59.94p 720/60p 720/29.97p 720/30p
1080p 1080/59.94p 1080/60p 1080/29.97p 1080/30p
Output Format
Frame Rate (Stream/Record)
50 Hz 25 Hz 23.98 Hz 24 Hz
720p 720/50p 720/25p
1080p 1080/50p 1080/25p 1080/23.98p 1080/24p
File Format
MP4
Codec: H.264, target bitrate up to 20,000 kbps
AAC-LC, 16 bits, 48 kHz, stereo, target bitrate up to 384 kbps
WAV Codec: Linear PCM, 16 bits, 48 kHz, stereo
* If either the streaming and recording format or the file played by the video player exceeds 1080/30p, the streaming and recording and video
player functions cannot be used simultaneously.
* If the bitrate setting for Streaming and Recording and the bitrate of the file played on Video Player exceeds 20,000 kbps, Streaming and Recording
and Video player cannot be used simultaneously
Video Player
File Format MP4
Codec: H.264, Average bit rate of 20,000 kbps or less, Maximum 1080/60p
AAC-LC, 16 bits, 48 kHz, stereo
* If either the streaming and recording format or the file played by the video player exceeds 1080/30p, the streaming and recording and video
player functions cannot be used simultaneously.
* If the bitrate setting for Streaming and Recording and the bitrate of the file played on Video Player exceeds 20,000 kbps, Streaming and Recording
and Video player cannot be used simultaneously.
Still Image File Format
Bitmap File (.bmp) Maximum 1920 x 1080 pixels, 24-bit color, uncompressed.
PNG File (.png) Maximum 1920 x 1080 pixels, 24-bit color
JPEG File (.jpg, .jpeg) Maximum 1920 x 1080 pixels, 24-bit color
* It can be stored up to 16 files in the internal memory.
* It can be exported in the SD Card and USB flash drive.
* PNG alpha channel supported.
Video Effects
Transition Cut, Mix (Dissolve/Fam/Nam), WIPE (8 types), SPLIT (2 types)
Composition
PinP x 4 (Square, Circle, Diamond), Keyer x 4 (Luminance Key, Chroma Key),
DSK x 2 (Luminance Key, Chroma Key, Alpha Key, External Key)
Others
Multi-View (3 types), Flip horizontal, Flip vertical, Still Image capture, Still Image playback,
Output fade (Audio, Video: White or Black), Test pattern output, Stream Delay
