Roland VR-120HD Direct Streaming AV Mixer - Manual (Page 70)

70
Live Streaming
Avoiding Sporadic Issues When Livestreaming (Safety Delay)
The VR-120HD comes with a built-in “safety delay” function that helps you to avoid unexpected troubles during livestreaming.
You can set the video and audio buffer (streaming delay time: “Stream Delay”) for the safety delay function.
If an accidental issue occurs within the streaming delay time, you can control the “switch to still image” and “mute audio” functions with the press of a
button, which prevents undesirable content from being streamed.
The safety delay function thus helps you to feel more at ease when livestreaming content, especially in situations like live events where there is no script or
guide.
Stream Delay
Safety Image
Accident
¹ The streaming delay time can be set in five-second intervals, to a
maximum of 60 seconds.
¹ This unit switches to the still image you imported as the “safety image”.
¹ The unit switches to the safety image only during livestreaming.
You can only check the switch to the safety image by looking at the
livestreamed video. The image shown on this unit’s display or the
video outputted via the HDMI OUT connector doesn’t switch to the
safety image.
¹ Use this function by assigning the USER buttons to switch to the still
image and to mute the audio.
Setting the Streaming Delay Time
1 . Select page 3 on the streaming/recording setup screen.
2 . Touch <Safety Delay> to configure the setting.
Value
Off, 5 sec–60 sec (five-second intervals)
3 . Press the [MENU] button to close the menu.
Using the safety delay function
1 . Select page 1 on the streaming/recording setup screen.
2 . Touch <ON AIR>.
3 . Touch <OK>.
Livestreaming starts.
4 . Touch <Safety Image> at the lower right corner of the
screen.
The streaming video switches to a still image, and the streaming audio
is muted.
Assigning safety delay to a USER button
You can assign the safety delay function to a USER button. This example
shows how to assign the safety delay function to the USER [3] button.
1 . Press the USER [SETUP] button.
The User Assign screen appears.
2 . For User 3, set the Category to “Stream/Record”, and the
Value to “Safety Image”.
Value Explanation
Safety Image
The safety delay function switches the streaming
video to a still image and mutes the streaming
audio.
3 . Press the [SETUP] button to close the screen.
