Menu List
Menu item Value (bold text: default value) Explanation
When Type =Video Follows Audio
Audio In 1–9/10 Target,
USB In Target,
Bluetooth In Target,
Audio Player Target,
HDMI 1–6 Target,
SDI 1–6 Target,
Video Player Target
Off, Input 1–8 Specifies the video that is output when audio is detected.
Threshold -50– 16 –0dB
Specifies the reference level at which the Video Follows Audio function operates. When
audio that exceeds this threshold is detected, the video is switched.
Audio Mix Target Off, Input 1–8
Specifies the video that is output when audio is detected in multiple mics. If this is “Off”,
video is switched in the order in which audio is detected.
Audio Silent Target Off, Input 1–8
Specifies the video that is output when there is no audio input from any mic. If this is “Off”,
the last selected video continues to be output.
Audio Redetection Time 0.0– 4 .0 –30.0sec Specifies the time after the video has switched until audio detection resumes.
Scan Transition Time 0.0– 1 .0 –4.0sec Specifies the video transition time.
When Type =PinP&Key 1–4 Scan, DSK 1, 2 Scan
Scan Sequence
Specifies the order in which video signals are shown.
Normal Switches in the order of HDMI 1
Ó
6, SDI 1
Ó
6, Still 1
Ó
16.
Reverse Switches in the order of Still 16
Ó
1, SDI 6
Ó
1, HDMI 6
Ó
1.
Random Switches randomly.
HDMI 1–6 Time Off, 1– 5 –120sec Specifies the time that the video is shown. Turn this “Off” to skip.
SDI 1–6 Time Off, 1– 5 –120sec Specifies the time that the video is shown. Turn this “Off” to skip.
Still 1–16 Time Off, 1– 5 –120sec Specifies the time that the still image is shown. Turn this “Off” to skip.
V.Player Time Off, 1– 5 –120sec Specifies the time that the video is shown. Turn this “Off” to skip.
21: Ctl/Exp
Menu item
Value (bold text: default
value)
Explanation
Ctl/Exp 1, 2 These settings for the footswitch or expression pedal connected to the CTL/EXP 1, 2 jacks.
Ctl/Exp Type
Settings for the devices (footswitch or expression pedal) connected to the CTL/EXP 1, 2 jacks.
Off Disables the CTL/EXP jack.
Ctl A & Ctl B Choose this if a footswitch is connected.
Exp Choose this if an expression pedal is connected.
When Ctl/Exp Type = Ctl A & Ctl B
Assign Specifies the functions that are assigned to Ctl A and Ctl B of the footswitch.
Ctl A
Ctl B
Category Value Explanation
N/A –– No function is assigned.
PGM Channel Select Input 1–8 Switches the video sent to the PGM bus.
PST Channel Select Input 1–8 Switches the video sent to the PST bus.
AUX Channel Select
HDMI 1–6, SDI 1–6, Still 1–16,
V.Player, Input 1–8
Switches the video sent to the AUX bus.
Input 1–8 Assign
HDMI 1–6, SDI 1–6, Still 1–16,
V.Player,
Stream/Record Status 1–2,
Date&Time(Analog/Digital(*)),
N/A
Changes the video assigned to Input 1–8.
(*)The analog/digital display changes in the “System
Ó
Date&Time
Ó
Clock Display Type” setting.
Still Output Still 1–16
Pauses the normal output, and previews or final outputs a cut of the still
image. Press the footswitch again to return to normal output.
Video Player Output ---
Pauses the normal output, and cuts to the preview/final output of the
video player image.
PinP&Key 1–4 Source
HDMI 1–6, SDI 1–6, Still 1–16,
V.Player, Input 1–8
Switches the video source of the inset screen.
DSK 1, 2 Source
HDMI 1–6, SDI 1–6, Still 1–16,
V.Player, Input 1–8
Switches the DSK video source.
