Other Functions
Menu item Value (bold text: default value) Explanation
AUX/Source Indicator
Sets whether to display the AUX/Source indicators in the monitor.
Color Explanation
Yellow Shows that this has been selected as an inset screen for the PinP & KEY.
Magenta Shows that this has been selected as a DSK video source.
Green Shows that this has been selected as an AUX bus video source.
Multi-View OFF, ON Turns the indicator on/off for multi-view.
Input-View OFF, ON Turns the indicator on/off for Input-view.
Still-View OFF, ON Turns the indicator on/off for Still-view.
External Rec Indicator Sets whether to display the External Rec indicator in the monitor.
When this is “ON”, a REC indicator showing that the camera’s REC button has been pressed is displayed, if the unit is
connected to a camera that supports the REC status function.
Multi-View OFF, ON Turns the indicator on/off for multi-view.
Input-View OFF, ON Turns the indicator on/off for Input-view.
Audio Level Meter Specifies whether to display the audio level meter in the monitor.
Multi-View OFF, ON Turns the indicator on/off for multi-view.
Input-View OFF, ON Turns the indicator on/off for Input-view.
Level Meter Position
HDMI In 1–6
Pre Fader(PFL)
Post Fader(AFL)
Sets the display position of the audio level meter.
SDI In 1–6
Video Player
Audio In 1–9/10
USB In
Bluetooth In
Audio Player
Main Bus
AUX 1–2 Bus
USB Out
Stream/Record
Preview Label Specifies whether to display the label in the monitor.
Jump To Setup Enter Jumps to the setup screen.
Multi-View OFF, ON Turns the label view on/off in the Multi-view.
Input-View OFF, ON Turns the label view on/off in the Input-view.
Still-View OFF, ON Turns the label view on/off in the Still-view.
Label Edit
HDMI 1–6, SDI 1–6, Still 1–16,
V.Player, PGM, SUB PGM,
PVW, AUX
Edit the label name shown in the monitor.
Press the [VALUE] knob to access the Label Edit screen.
Label Size Small, Normal Specifies the text size of the label shown in the monitor.
Multi-View Layout Specifies the videos to be shown in the PVW section (Left) and PGM section (Right) in the multi-view.
Left
Right
Program Final output video. This is the default setting for “Right”.
Sub Program Sub Program bus video
Preview Preview output video. This is the default setting for “Left”.
AUX AUX bus video
Black Black screen
Input-View Layout Configures the layout in input-view.
Jump To Setup Enter Jumps to the setup screen.
Input 1–16
HDMI 1–6
SDI 1–6
Still 1–16
V.Player
Input 1–8
Stream/Record Status 1–2
Date&Time(Analog/Digital(*))
N/A
Sets the video to display for Input 1–16.
(*)The analog/digital display changes in the “System
Ó
Date&Time
Ó
Clock Display Type”
setting.
Auto Input Detect OFF , ON
Turns the auto input detect function on/off.
When this is “ON”, input is automatically detected, and the video is switched when input
from the final output video is interrupted.
Auto Fan Control OFF, ON
Turns the auto fan control function on/off.
When this is “ON”, this function controls the fan according to the internal temperature of this
unit.
