33
Video Operations
Freezing the Input Video (Freeze)
Here’s how to temporarily freeze the input video (freeze function).
You can apply transition effects during a video freeze.
MEMO
You can assign the freeze function to a USER button to turn the video
on/off (“Assigning Functions to the USER Buttons” (p. 90)).
The freeze function is assigned to the USER [1] button by factory
default.
Setting the Operation Mode
There are two freeze modes: the “All mode” for freezing all input video,
and the “Select mode” that freezes only the input video you specify. Set
the mode that matches your needs.
1 . Press the USER [SETUP] button.
The User Assign screen appears.
2 . Touch User 1 <Setup>.
The Freeze function setup screen appears.
3 . Touch <Type> to select the operating mode.
Value Explanation
All Freezes all video that is being input.
Select Freezes only the specified input video.
If “Select” is selected
4 . Touch the screen to specify a source from “HDMI 1” to “SDI
6”.
Value Explanation
Enable The input video freezes.
Disable The input video does not freeze.
5 . Press the [SETUP] button to close the screen.
Freezing the Input Video
1 . Press the USER [1] (FREEZE) button to turn freeze on (the
button lights up).
The input video freezes.
2 . To turn freeze off, press the USER [1] (FREEZE) button again.
