Menu List
Menu item Value (bold text: default value) Explanation
Audio In 3–6
Audio In 3/4 (Linked),
Audio In 5/6 (Linked)
Adjusts the audio that is input from the AUDIO IN 3 – 6 jacks.
* “Audio In 3/4 (Linked)” “Audio In 5/6 (Linked)” is shown when “Stereo Link” is “ON”.
Jump To Setup Enter Jumps to the setup screen.
Analog Gain 0 –68db Adjusts the input gain (sensitivity) in the analog domain.
Digital Gain -42.0– 0 .0 –42.0dB
Adjusts the input gain (sensitivity) in the digital domain (after conversion from analog to
digital).
Input Level -INF –0.0–10.0dB
Adjusts the input volume.
This can also be adjusted by the [3]–[6] fader. (*10)
Input Mute OFF , ON Turns the mute function on/off. When this is “ON”, the input audio is temporarily silenced.
Phantom +48V OFF , ON
Turns the phantom power on/off. When this is “ON”, phantom power is supplied via the AUDIO
IN jacks (XLR).
* Changing “Stereo Link” settings automatically turns “Phantom +48V” settings “OFF”.
Pan (*11) Left– Center –Right Adjusts the stereo position (pan).
Stereo Link OFF , ON
Turns the stereo link function on/off. When this is “ON”, Audio In 3 and 4 (5 and 6) are
linked, and operate as a stereo channel.
* When stereo link is turned on, the settings of Audio In 3 (5) are applied to Audio In 4 (6).
Solo OFF , ON
Turns the solo function on/off. Only the audio for which this is “ON” is heard in the
headphones.
* The solo function applies to the headphone output. It does not affect output other
than the headphones.
Delay
0 .0 –500msec
(0 –25.0/29.9/30.0frame)
Adjusts the delay time of the audio.
Effect Outputs audio with a delay.
Reverb Send 0 –127 Adjusts the amount of audio sent to reverb.
Main Bus This configures the Main bus.
Send OFF, ON When this is “ON”, audio is sent to the Main bus.
AUX 1 Bus This configures the AUX 1 bus.
Send Level -INF –10.0dB These parameters adjust the amount of audio sent to the AUX 1 bus.
Send Point
Dry Sends the source audio with no effects applied.
Pre Fader
Sends the effect-applied audio.
The send volume is constant, regardless of the volume (Input Level).
Post Fader
Sends the effect-applied audio.
The send volume can be changed by adjusting the volume (Input Level).
AUX 2 Bus This configures the AUX 2 bus.
Send Level -INF –10.0dB These parameters adjust the amount of audio sent to the AUX 2 bus.
Send Point
Dry Sends the source audio with no effects applied.
Pre Fader
Sends the effect-applied audio.
The send volume is constant, regardless of the volume (Input Level).
Post Fader
Sends the effect-applied audio.
The send volume can be changed by adjusting the volume (Input Level).
High Pass Filter 80Hz OFF , ON
Turns the high-pass filter on/off.
Effect Cuts off unneeded low-band audio. The cutoff frequency is 80 Hz.
Noise Gate OFF , ON
Turns the noise gate on/off.
Effect
Eliminates audio that is lower than the specified threshold level. This is effective
when the noise that you want to remove is separate from the audio that you
want to keep, and can be used to remove hiss or other noise that is heard during
periods of silence.
Threshold -80– -48 –0dB
Specifies the level used as the threshold for removing audio. Audio below the level set here
is removed.
Release 30– 500 –5000msec
Adjusts the length of time until the audio is fully attenuated after audio falls below the
threshold.
De-Esser OFF , ON
Turns the de-esser on/off.
Effect Reduces sibilant noise (the sounds you hear when pronouncing “s” words and
other hissing sounds).
Sens 0– 80 –100 Adjusts the sensitivity with which sibilants are detected.
Depth 0– 64 –100 Adjusts the intensity of the effect.
Compressor OFF , ON
Turns the compressor on/off.
Effect
Audio that exceeds the specified threshold level is compressed. This reduces the
difference between the maximum volume and minimum volume, making the
audio more comfortable for listening.
Threshold -50– -8 –0dB
Specifies the level used as the threshold at which the compressor is applied.
Compression is applied to audio that exceeds the threshold.
