Audio Operations
Using an Effect Preset
The VR-120HD is equipped with effects that are adjusted for specific
environments. These are called “effect presets”.
The effect presets are created using a combination of four effects (high-
pass filter, compressor, equalizer, noise gate).
Simply by selecting an effect preset, you can easily apply an effect that’s
appropriate for your situation.
MEMO
¹ To make detailed adjustments to a preset, edit the high-pass filter,
compressor, equalizer and noise gate settings on the channel
setup screen (page 2).
¹ You cannot overwrite the effect presets. Use the scene memories
to save the settings for presets you’ve edited (p. 71).
¹ When you load an effect preset, each preset setting is restored to
its default setting (factory defaults).
1 . Touch the page tab at the top right-hand corner of the
channel setup screen to select page 2.
2 . Select an effect preset by touching the screen.
Value Explanation
Default For line input (default setting)
Meeting For meetings
Interview For interviews
Ambient Mic For capturing ambient sound
Windy Field For capturing ambient sound in a windy area
A confirmation message appears.
* If you decide to cancel, press the [EXIT] button.
3 . Use the [VALUE] knob to select “OK”, and press the [VALUE]
knob.
The effect preset is loaded.
4 . Configure the settings for each effect as necessary.
Touch the onscreen graphics to enlarge the settings for the effect. You
can also directly drag a point on the graph onscreen to edit.
Á Noise gate
Á Compressor
Á Equalizer, High-pass filter
* For details on the parameters, refer to “8: Audio Input” (p. 110).
