Roland VR-120HD Direct Streaming AV Mixer - Manual (Page 115)

115
Menu List
Menu item Value (bold text: default value) Explanation
Equalizer OFF , ON
Turns the equalizer on/off.
Effect
This is a 4-band parametric equalizer. It lets you shape the character of the sound by
boosting or cutting four frequency regions.
Hi Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the high band.
Hi Freq 1.00– 10 .0 –20.0kHz Adjusts the center frequency when changing the tone quality in the high band.
Hi-Mid Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the high-midrange band.
Hi-Mid Freq 20.0Hz– 2 .00kHz –20.0kHz
Adjusts the center frequency when changing the tone quality in the high-midrange
band.
Hi-Mid Q 0.5– 1 .0 –16.0
Adjusts the width of the frequency band when boosting or attenuating high-midrange
band.
Lo-Mid Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the low-midrange band.
Lo-Mid Freq 20.0Hz– 500Hz –20.0kHz Adjusts the center frequency when changing the tone quality in the low-midrange band.
Lo-Mid Q 0.5– 1 .0 –16.0
Adjusts the width of the frequency band when boosting or attenuating low-midrange
band.
Lo Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the low band.
Lo Freq 20.0Hz– 100Hz –2.00kHz Adjusts the center frequency when changing the tone quality in the low band.
