128
Menu List
9: Audio Output
Menu item Value (bold text: default value) Explanation
Output Assign Specifies the audio bus that is assigned to each connector.
Jump To Setup Enter Jumps to the setup screen.
Audio Out 1/2 (XLR)
Main Bus , AUX 1 Bus, AUX 2 Bus,
Monitor
Main Bus:
All input audio is mixed and output (master output).
AUX 1 Bus, AUX 2 Bus:
Only the input audio sent to the AUX bus is mixed and output. This allows you to output
audio that is different than the master output.
Monitor:
This outputs the same audio as what you hear in the headphones.
Audio Out 3/4 (XLR)
Main Bus , AUX 1 Bus, AUX 2 Bus,
Monitor
Audio Out (RCA)
Main Bus , AUX 1 Bus, AUX 2 Bus,
Monitor
Phones Out/Monitor Main Bus , AUX 1 Bus, AUX 2 Bus
USB Out Main Bus , AUX 1 Bus, AUX 2 Bus
Stream/Record Main Bus , AUX 1 Bus, AUX 2 Bus
Audio Record Main Bus , AUX 1 Bus, AUX 2 Bus
HDMI Out 1–3
Main Bus , AUX 1 Bus, AUX 2 Bus,
Monitor
SDI Out 1–3
Main Bus , AUX 1 Bus, AUX 2 Bus,
Monitor
Main Bus Adjusts the audio of the MAIN bus.
Jump To Setup Enter Jumps to the setup screen.
Level -INF– 0 .0 –10.0dB
Adjusts the output volume.
This can also be adjusted by the [MAIN] fader.
Mute OFF , ON Turns the mute function on/off. When this is “ON”, the input audio is temporarily silenced.
Solo OFF , ON
Turns the solo function on/off. Only the audio for which this is “ON” is heard in the
headphones.
* The solo function applies to the headphone output. It does not affect output other than
the headphones.
Delay
0 .0 –500msec
(0 –25.0/29.9/30.0frame)
Adjusts the delay time of the audio.
Effect Outputs audio with a delay.
Reverb OFF , ON
Turns reverb on/off.
Effect Adds reverberation to the sound.
Level 0 –127 This adjusts the depth of the overall reverb.
Type
Specifies the reverb type.
Room Produces the natural-sounding reverberation of a room.
Hall Produces the reverberation that is typical of a performance in a concert hall.
Size 1– 10 –20 Specifies the size of the room. The larger the value, the longer the reverb time.
Return Level -INF– 0 .0 –10.0dB Adjusts how much reverb is sent back to the main bus.
Equalizer OFF , ON
Turns the equalizer on/off.
Effect
This is a 4-band parametric equalizer. It lets you shape the character of the sound by boosting
or cutting four frequency regions.
Hi Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the high band.
Hi Freq 1.00– 10 .0 –20.0kHz Adjusts the center frequency when changing the tone quality in the high band.
Hi-Mid Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the high-midrange band.
Hi-Mid Freq 20.0Hz– 2 .00kHz –20.0kHz Adjusts the center frequency when changing the tone quality in the high-midrange band.
Hi-Mid Q 0.5– 1 .0 –16.0
Adjusts the width of the frequency band when boosting or attenuating high-midrange
band.
Lo-Mid Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the low-midrange band.
Lo-Mid Freq 20.0Hz– 500Hz –20.0kHz Adjusts the center frequency when changing the tone quality in the low-midrange band.
Lo-Mid Q 0.5– 1 .0 –16.0 Adjusts the width of the frequency band when boosting or attenuating low-midrange band.
Lo Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the low band.
