Menu List
Menu item
Value (bold text: default
value)
Explanation
When Ctl/Exp Type = Exp
Assign Specifies the function that is assigned to the expression pedal.
Exp
Category Value Explanation
N/A –– No function is assigned.
Video Fader Fade, Cut
Fade:
Operates the video fader.
Cut:
Cuts between the final output video and the preview video.
Still Output Still 1–16
Pauses the normal output, and previews or final outputs a cut of the still
image.
Video Player Output ---
Pauses the normal output, and cuts to the preview/final output of the video player
image.
Audio Input Level
Audio In 1–9/10, USB In,
Bluetooth In, Audio Player
HDMI 1–6, SDI 1–6, V.Player
Adjusts the input volume.
Audio Output Level
Main Bus, AUX 1 Bus, AUX 2
Bus, USB Out, Stream/Record Adjusts the output volume.
Voice Changer
Audio In 1 Pitch,
Audio In 1 Formant,
Audio In 1 Mix,
Audio In 2 Pitch,
Audio In 2 Formant,
Audio In 2 Mix
Adjusts the balance between the unprocessed voice (0) and the voice
processed by the effect (100).
Reverb Level –– Adjusts the amount of sound that is returned from the reverb (return level).
Exp Calibration Enter
Displays the Exp Calibrate screen.
Following the direction on the screen, calibrate (adjust) the expression pedal.
The first time you use the expression pedal, be sure to execute calibration so that the pedal will operate
optimally.
In some cases, the expression pedal might no longer be operating optimally because of the passage of
time or the conditions of use. In such cases you should also execute expression pedal calibration.
22: RS-232/Tally/GPO/GPI
Menu item Value (bold text: default value) Explanation
RS-232 These are the settings for transmitting/receiving RS-232 commands.
RS-232 OFF, ON When this is “ON”, RS-232 commands can be transmitted and received.
Baudrate 9600, 38400, 115200 Specifies the communication speed (bps) of the RS-232 connector.
Tally/GPO These are settings for tally signals or control signals that are output from the TALLY/GPIO connector.
Template
HDMI Tally , SDI Tally, GPO,
HDMI Tally/GPO, SDI Tally/
GPO
Selects a TALLY/GPO 1–16 settings template.
Press the [VALUE] knob to apply the template settings to “TALLY/GPO 1–16”.
TALLY/GPO 1–16
Assigns the tally signal to TALLY/GPIO connector pins 1–16.
PGM HDMI 1–6
PGM SDI 1–6
A tally signal is output when the video sent from the connector in question is the final output.
PGM Still 1–16 A tally signal is output when the still image in question is the final output.
PGM Video Player A tally signal is output when the video sent from the video player in question is the final output.
PGM Input 1–8
A tally signal is output when the final output video is selected using the VIDEO SWITCHER button in
question (the button lights up red).
PST HDMI 1–6
PST SDI 1–6
A tally signal is output when the video sent from the connector in question is the preview output.
PST Still 1–16 A tally signal is output when the still image in question is the preview output.
PST Video Player A tally signal is output when the video sent from the video player in question is the preview output.
PST Input 1–8
A tally signal is output when the preview output video is selected using the VIDEO SWITCHER button in
question (the button lights up green).
Assigns the GPO to TALLY/GPIO connector pins 1–16.
GPO 1–16
A control signal is output when you press a USER button or the footswitch, or assign a GPO output
function to a GPI pin.
