93
Other Functions
Using a Footswitch
You can use a footswitch connected to the CTL/EXP 1 and 2 jacks to control the VR-120HD with your foot. You can assign various functions to the
footswitch.
1 . [MENU] button
Ó
“Ctl/Exp”
Ó
“Ctl/Exp 1” or “Ctl/Exp 2”
Ó
select “Ctl/Exp Type”, and press the [VALUE] knob.
2 . Set the connected device to “Ctl A & Ctl B” (the footswitch)
using the [VALUE] knob, and press the [VALUE] knob.
3 . Use the [VALUE] knob to select Ctl A Or Ctl B “Category” and
“Value”, and press the [VALUE] knob.
4 . Use the [VALUE] knob to select the function that you want
to assign to Ctl A or Ctl B of the footswitch, and press the
[VALUE] knob.
Á Category
Value Explanation
N/A No function is assigned.
PGM Channel Select Switches the video sent to the PGM bus.
PST Channel Select Switches the video sent to the PST bus.
AUX Channel Select Switches the video sent to the AUX bus.
Input 1–8 Assign Changes the video assigned to Input 1–8.
Still Output
Pauses the normal output, and previews or
final outputs a cut of the still image.
Video Player Output
Pauses the normal output, and cuts to the
preview/final output of the video player
image.
PinP&Key 1–4 Source
Switches the video source of the inset
screen.
DSK 1, 2 Source Switches the DSK video source.
Button Control
This works the same as when you press the
button selected in “VALUE”.
Audio Input Mute
Turns the mute function on/off for the
input audio.
Audio Output Mute
Turns the mute function on/off for the
output audio.
Audio Input Solo
Turns the solo function on/off for the input
audio.
Audio Output Solo
Turns the solo function on/off for the
output audio.
Voice Changer Turns the voice changer on/off.
Auto Mixing Turns the auto mixing on/off.
Reverb (Momentary)
Reverb turns on only while you press the
footswitch.
Reverb (Alternate) Turns reverb on/off.
Output Fade The final output video fades in/out.
Load Memory Recalls a scene memory.
Input Scan
Each time you press the footswitch, the
Input 1–8 video changes in order.
Scene Memory Scan
Each time you press the footswitch, scene
memories 1–32 are recalled in order.
Value Explanation
PinP&Key 1–4 Scan
The PinP & KEY 1–4 inset screen videos
switch in order each time you press the
footswitch.
DSK 1, 2 Scan
The DSK 1 and 2 caption video switches in
order each time you press the footswitch.
Macro Execute
Executes a macro (a series of recorded
operations).
Sequencer
When the sequencer function is on, this
works the same as when you press the
button selected in “VALUE”.
GPO (One Shot) Outputs a control signal for 0.5 seconds.
GPO (Alternate)
The control signal output is switched on/
off with each press of the footswitch.
Á Value
Configures the detailed settings related to “Category”.
5 . Press the [MENU] button to close the menu.
MEMO
¹ See “Connecting a Footswitch” (p. 9) for how to connect a
footswitch to this unit.
¹ If a single-pedal type footswitch such as the BOSS FS-5U is
connected using a phone cable (mono), the function assigned by
“Ctl B” is enabled.
